AC 11kw Oilless Low Pressure Piston Air Compressor With Tank For Mining 40 Bar

China AC 11kw Oilless Low Pressure Piston Air Compressor With Tank For Mining 40 Bar supplier
AC 11kw Oilless Low Pressure Piston Air Compressor With Tank For Mining 40 Bar supplier AC 11kw Oilless Low Pressure Piston Air Compressor With Tank For Mining 40 Bar supplier

Large Image :  AC 11kw Oilless Low Pressure Piston Air Compressor With Tank For Mining 40 Bar

Product Details:

Place of Origin: China
Brand Name: StepChina
Model Number: WH-1.0/40

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: wooden case
Delivery Time: 15 work days
Contact Now
Detailed Product Description
Power Source: AC Brand Name: Hengda
Model: WH-1.0/40 Speed: 790 R.p.m
Weight: 470 Kg Diemnsion: 1400*840*840 Mm

AC 11kw Oilless Low Pressure Piston Air Compressor With Tank For Mining 40 Bar



 Quick Detail:

Name

Air compressor

Brand Name

Hengda

Capacity

1 M3/Min

Pressure

40 Bar

Function

compressed air

Usage

Supply compressed air for Blowing PET bottle







Applications:

1. Supply compressed air

2. Supply comressed air for pneumatic parts of filling machine, packing machines.



Specifications

High pressure compressor used high pressure air compressor
1. Air capacity: 1.0 M3/min
2. working pressure: 40bar
3. Power: 11kw





30BAR-40BAR High pressure compressor 40bar High pressure compressor used high pressure air compressor



1. Main data



Model

Air capacity

(M3/min)

Working pressure

(Bar)

Power(Kw)

Speed(r.p.m)

Weight(Kg)

VH-0.7/30

0.7

30BAR

7.5

680

310

WH-1.0/30

1.0

11

600

430

WH-1.2/30

1.2

15

760

450

WH-1.5/30

1.5

18.5

790

520

WH-2.0/30

2.0

22

670

610

WH-2.35/30

2.35

25

760

620

2-WH-3.0/30

3.0

2*18.5

790

1150

3-WH-3.6/30

3.6

3*15

700

1580

VH-0.17/35

0.17

35BAR

2.2

660

110

VH-0.65/35

0.65

9.0

605

420

WH-1.1/35

1.1

15

900

475

WH-2.0/35

2.0

22

670

615

WH-2.2/35

2.2

25

735

600

VH-0.3/40

0.3

40BAR

5.5

500

290

WH-1.0/40

1.0

11

790

470

49SH-2.6/40

2.6

25

625

900

49SH-3.0/40

3.0

30

695

920

2-49SH-6.0/40

6.0

2*30

695

2100

4-WH-4.0/40

4.0

4*11

790

2400

6-WH-6.0/40

6.0

6*11

790

3600







2. Inspection method:

CAGI



3. Inspection standard:

-AISI

-AMS

-ANSI

-ASME

-ASTM

-AGMA

-AGMA

-NEMA

-VDI

-CAGI-NPEUROP

-MS



4. Technical characteristics:



4.1 Automatic pressure unloading system, ensure machine starting without loading.

4.2 With exhaust check valve on outlet.

4.3 Removable type inlet silencing filter, 10 micron precision.

4.4 Normal inertia flywheel, 2 root V belt drive.

4.5 Splashing lubrication to all moving Parts.

4.6 Light alloy pistons, with PTFE.

4.7 Cast iron cylinder head, independent valve seat.

4.8 Automatic hoop valve piston rings, big flow, more action, high efficiency.

4.9 World famous brand rolling bearing, ensure the stable operation unit.

4.10 Enough space between the cylinder and the crankcase design, avoid friction between connecting rod, moving parts and crankcase.

4.11 With Safety Valve Between after-cooling



The quality of our products can keep up with international standard as introduction of foreign technology.

High efficiency,high performance engergy saving,reliability and long lift are the principle characteristics o HENGDA high pressure air compressor.The Free air delivery from 0.15m3/min to 6.0m3/min.HENGDA makes a very wide model of rang of compressor to meet a wide rand of industrial application and requirement , especially for PET BLOWING Industry. Every machine is equipped with starting,unloading solenoid valve,auto condensate drain valve and advanced capacity control to make machine to operate safe and stable.



.AC 11kw Oilless Low Pressure Piston Air Compressor With Tank For Mining 40 Bar
